Inconel 625 Seamless Welded Pipe

Inconel 625 Pipes and Tubes Exporter, Inconel 625 Rectangular Tubing Supplier in Mumbai , Inconel 625 Round Pipe, Inconel Alloy 625 Pipes Manufacturer in India, Inconel 625 Welded Pipe, Inconel Pipe.

Table of Content

• What is Inconel 625 Seamless Pipes
• Specification of Inconel 625 Seamless Pipes
• Equivalent Grade of Inconel 625 Seamless Pipes
• Chemical Composition of Inconel 625 Seamless Pipes
• Applications and Uses of Inconel 625 Seamless Pipes
• Packaging of Inconel 625 Seamless Pipes
• Testing of Inconel 625 Seamless Pipes
• People also Search For Inconel 625 Seamless Pipes
• Export Destinations
• Domestic Supply

Silicon Steels is one of the prominent suppliers and manufacturers of high-quality Inconel 625 Seamless Pipe. These Inconel 625 tubes should be machined ideally in the annealed condition. Our Inconel 625 Welded Pipe is similar to other nickel-chrome filling metals' Operational characteristics. Welded tungsten electrodes or consumable electrodes can be used to solder those Inconel 625 Welded pipes through gas-blocking processes. However, our Inconel 625 Rectangular Hollow pipes easily harden the work and may require intermediate annealing treatments for complicated part shaping operations.

Inconel Alloy 625 Round Pipes, 625 Inconel Tube, 625 Inconel Tubing, Inconel 625 Seamless Tubes Manufacturer, 625 Seamless and Welded Inconel Pipes Stockist, 625 Inconel Seamless Piping Stockist.

The high nickel content used to fuse-welded tubes of Inconel Alloy 625 Seamless Round Tubing allows a wide variety of extremely corrosive media-containing conditions to withstand metal. There is virtually no assault on the Inconel 625 stainless steel pipe in moderate conditions such as the soil, acidic salts, fresh water and seawater, or in the presence of alkaline material. The combination of nickel and chromium in the ASTM B705 Inconel Alloy 625 Welded Tubes is extremely useful in a more severe corrosive environment.

Inconel 625 Welded tubes are especially resistant to oxidation and high temperature. Its ability to withstand 1800 ° F is significant. In terms of being able to handle cyclic heating and cooling, it ranks highly compared with other alloys designed for extreme conditions. The elements in alloy 625 will not corrode when exposed to fresh or salt water, neutral or alkaline outlets. This is due largely in part to the chromium content.

Specification :

Specifications	ASME SB-444 ASME S B-444 ASME SB-444 ASME SB-725
Seamless Pipes & Tubes Sizes	1 / 2" NB - 8" NB
Welded Pipes & Tubes Sizes	6" NB - 24" NB
Outer Diameter	6.0-630mm
Schedule	SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Thickness	0.3mm – 50 mm
Type	Seamless / ERW / Welded/ Fabricated
Form	Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tubes
Length	Single Random, Double Random & Cut Length
End	Plain End, Beveled End, Treaded

Types of Inconel 625 Pipes :

	ASTM B444 Inconel 625 Sch 40 Seamless Pipe ASME SB444 UNS N06625 Sch 160 Seamless Pipe Werkstoff Nr. 2.4856 2B Finish Seamless Pipe	Afnor Nc22Dnb4M Galvanized Seamless Pipe EN Nicr22Mo9Nb Ba Finish Seamless Pipe JIS Ncf 625 Electropolished Seamless Pipe	BS Na 21 No.4 Seamless Pipe Gost Хн75Мбтю Sch 40 Seamless Pipe
	ASTM B444 Inconel 625 Sch 40 Tube ASME SB444 UNS N06625 Sch 160 Tube Werkstoff Nr. 2.4856 2B Finish Tube	Afnor Nc22Dnb4M Galvanized Tube EN Nicr22Mo9Nb Ba Finish Tube JIS Ncf 625 Electropolished Tube	BS Na 21 No.4 Tube Gost Хн75Мбтю Sch 40 Tube
	ASTM B444 Inconel 625 Sch 40 Round Pipe ASME SB444 UNS N06625 Sch 160 Round Pipe Werkstoff Nr. 2.4856 2B Finish Round Pipe	Afnor Nc22Dnb4M Galvanized Round Pipe EN Nicr22Mo9Nb Ba Finish Round Pipe JIS Ncf 625 Electropolished Round Pipe	BS Na 21 No.4 Round Pipe Gost Хн75Мбтю Sch 40 Round Pipe
	ASTM B444 Inconel 625 Sch 40 Square Pipe ASME SB444 UNS N06625 Sch 160 Square Pipe Werkstoff Nr. 2.4856 2B Finish Square Pipe	Afnor Nc22Dnb4M Galvanized Square Pipe EN Nicr22Mo9Nb Ba Finish Square Pipe JIS Ncf 625 Electropolished Square Pipe	BS Na 21 No.4 Square Pipe Gost Хн75Мбтю Sch 40 Square Pipe
	ASTM B444 Inconel 625 Sch 40 Rectangle Pipe ASME SB444 UNS N06625 Sch 160 Rectangle Pipe Werkstoff Nr. 2.4856 2B Finish Rectangle Pipe	Afnor Nc22Dnb4M Galvanized Rectangle Pipe EN Nicr22Mo9Nb Ba Finish Rectangle Pipe JIS Ncf 625 Electropolished Rectangle Pipe	BS Na 21 No.4 Rectangle Pipe Gost Хн75Мбтю Sch 40 Rectangle Pipe
	ASTM B444 Inconel 625 Sch 40 IBR Pipe ASME SB444 UNS N06625 Sch 160 IBR Pipe Werkstoff Nr. 2.4856 2B Finish IBR Pipe	Afnor Nc22Dnb4M Galvanized IBR Pipe EN Nicr22Mo9Nb Ba Finish IBR Pipe JIS Ncf 625 Electropolished IBR Pipe	BS Na 21 No.4 IBR Pipe Gost Хн75Мбтю Sch 40 IBR Pipe
	ASTM B444 Inconel 625 Sch 40 Fabricated Pipe ASME SB444 UNS N06625 Sch 160 Fabricated Pipe Werkstoff Nr. 2.4856 2B Finish Fabricated Pipe	Afnor Nc22Dnb4M Galvanized Fabricated Pipe EN Nicr22Mo9Nb Ba Finish Fabricated Pipe JIS Ncf 625 Electropolished Fabricated Pipe	BS Na 21 No.4 Fabricated Pipe Gost Хн75Мбтю Sch 40 Fabricated Pipe
	ASTM B444 Inconel 625 Sch 40 Odd Size Pipe ASME SB444 UNS N06625 Sch 160 Odd Size Pipe Werkstoff Nr. 2.4856 2B Finish Odd Size Pipe	Afnor Nc22Dnb4M Galvanized Odd Size Pipe EN Nicr22Mo9Nb Ba Finish Odd Size Pipe JIS Ncf 625 Electropolished Odd Size Pipe	BS Na 21 No.4 Odd Size Pipe Gost Хн75Мбтю Sch 40 Odd Size Pipe
	ASTM B444 Inconel 625 Sch 40 Cold Drawn Seamless Tubes ASME SB444 UNS N06625 Sch 160 Cold Drawn Seamless Tubes Werkstoff Nr. 2.4856 2B Finish Cold Drawn Seamless Tubes	Afnor Nc22Dnb4M Galvanized Cold Drawn Seamless Tubes EN Nicr22Mo9Nb Ba Finish Cold Drawn Seamless Tubes JIS Ncf 625 Electropolished Cold Drawn Seamless Tubes	BS Na 21 No.4 Cold Drawn Seamless Tubes Gost Хн75Мбтю Sch 40 Cold Drawn Seamless Tubes

Equivalent Grade :

Grade	UNS No	Old British		Euronorm		GOST	Japanese JIS
		BS	En	No	AFNOR
Inconel 625	N06625	NA 21	NiCr22Mo9Nb	2.4856	NC22DNB4M	ХН75МБТЮ	NCF 625

Chemical Composition :

Grade		C	Mn	Si	Fe	S	Cr2	Al-Ti	Ni
625	min.	–	–	–	–	–	20.0	–	58.0
	max.	0.10	0.50	0.50	5.0	0.015	23.0	0.40	–

Inconel 625 Pipes Price List (2023 Updated)

Product	Price (Per Kg)
Inconel Tube	₹ 1,000/
Inconel Welded Pipes	₹ 200/
Inconel Pipes	₹ 1,500/
Inconel Alloy 625 Seamless Tube	₹ 1,500/
Inconel Steel Pipes	₹ 130/

Dimensions of Inconel 625 Pipes

Inconel 625 Pipes Weight Chart

NPS	Outside Diameter		Wall Thickness			Weight	Weight
	in	mm	in	mm	Sched	kg/Mtr	Lb/ft
1/2″	0.840	21	0.109	2.769	40 STD	1.268	0.851
			0.147	3.734	80 STD	1.621	1.088
3/4″	1.050	27	0.113	2.870	40 STD	1.684	1.131
			0.154	3.912	80 STD	2.195	1.474
1″	1.315	33	0.133	3.378	40 STD	2.501	1.679
			0.179	4.547	80 STD	3.325	2.172
1 1/4″	1.660	42	0.140	3.556	40 STD	3.385	2.273
			0.191	4.851	80 STD	4.464	2.997
1 1/2″	1.900	48	0.145	3.683	40 STD	4.048	2.718
			0.200	5.080	80 STD	5.409	3.361
2″	2.375	60	0.154	3.912	40 STD	5.441	3.653
			0.218	5.537	80 STD	7.480	5.022
2 1/2″	2.875	73	0.203	5.516	40 STD	8.629	5.793
			0.276	7.010	80 STD	11.411	7.661
3″	3.500	89	0.216	5.486	40 STD	11.284	7.576
			0.300	7.620	80 STD	15.272	10.253
4″	4.500	114	0.237	6.020		16.073	10.790
			0.337	8.560		22.318	14.983
6″	6.625	168	0.188	4.775		19.252	12.924
			0.203	5.516		20.739	13.923
			0.219	5.563		22.318	14.983
			0.250	6.350		25.354	17.021
			0.280	7.112	40 STD	58.263	18.974
			0.312	7.925		31.334	21.036
			0.375	9.525		37.285	25.031
			0.432	10.973	80 XHY	42.561	28.573
			0.500	12.700		48.719	32.708
8″	8.625	219	0.188	4.775		25.233	16.940
			0.203	5.156		27.198	18.259
			0.219	5.563		29.286	19.661
			0.250	6.350	20	33.308	22.361
			0.277	7.036	30	36.786	24.696
			0.322	8.179	40	42.352	28.554
			0.375	9.525		49.216	33.041
			0.406	10.312	60	53.085	35.638
			0.500	12.700	80 XHY	64.627	43.388
10″	10.750	273	0.188	4.775		31.588	21.207
			0.219	5.563		36.689	24.631
			0.250	6.350	20	41.759	28.035
			0.307	7.798	30	51.002	34.240
			0.344	8.738		56.946	38.231
			0.365	9.271	40 STD	63.301	40.483
			0.438	11.125		71.852	48.238
			0.500	12.700	60 XHY	81.530	54.735
			0.594	15.088	80	95.969	64.429
12″	12.750	324	0.188	4.775		37.570	25.222
			0.219	5.563		43.657	29.309
			0.250	6.350		49.713	33.375
			0.281	7.137		55.739	37.420
			0.312	7.925		61.735	41.445
			0.375	9.525		73.824	49.562
			0.406	10.312		79.727	53.525
			0.500	12.700		97.438	65.415
			0.562	14.275		108.966	73.154
14″	14.000	356	0.188	4.775		41.308	27.732
			0.219	5.563		48.012	32.233
			0.250	6.350	20	54.685	36.713
			0.281	7.137		61.327	41.172
			0.312	7.925		67.939	45.611
			0.375	9.525	STD	81.281	54.568
			0.438	11.125	40	94.498	63.441
			0.500	12.700	XHY	107.381	72.090
			0.625	15.875		132.983	89.278
16”	16.000	406	0.188	4.775		47.290	21.748
			0.219	5.563		54.980	36.910
			0.250	6.350	10	62.639	42.053
			0.281	7.137		70.268	47.174
			0.312	7.925	20	77.866	52.275
			0.344	8.738		85.677	57.519
			0.375	9.525	30 STD	93.213	62.578
			0.438	11.125		108.433	72.797
			0.500	12.700	40 XHY	123.289	82.770
18″	18.000	457	0.219	5.563		61.948	41.588
			0.250	6.350		70.593	47.393
			0.281	7.137		79.208	53.176
			0.312	7.925	20	87.792	58.939
			0.375	9.525	STD	105.144	70.588
			0.438	11.125	30	122.369	82.152
			0.500	12.700	XHY	139.198	93.450
			0.562	14.275	40	155.904	104.666
			0.625	15.875		172.754	115.978
20″	20.000	508	0.250	6.350		78.547	52.733
			0.282	7.163		88.458	59.386
			0.312	7.925		97.719	65.604
			0.375	9.525	20 STD	117.075	78.598
			0.438	11.125		136.305	91.508
			0.500	12.700	30 XHY	155.106	104.130
			0.594	15.088	40	183.378	123.110
			0.625	15.875		192.640	129.328
			0.688	17.475		211.368	141.901
24″	24.000	610	0.250	6.350		94.456	63.413
			0.281	7.137		106.029	71.183
			0.312	7.925		117.573	18.932
			0.375	9.525	20 STD	140.938	64.618
			0.438	11.125		164.176	110.219
			0.500	12.700	XHY	186.923	125.490
			0.625	15.875		232.410	156.028
			0.688	17.475	40	255.148	171.293
			0.750	19.050		277.401	186.233
30″	30.000	762	0.250	6.350		118.318	79.433
			0.281	7.137		132.851	89.189
			0.312	7.925	10	147.353	98.925
			0.375	9.525	STD	176.731	118.648
			0.438	11.125		205.983	138.286
			0.500	12.700	20 XHY	234.647	157.530
			0.625	15.875	30	292.066	196.078
			0.688	17.475		320.817	215.380
			0.750	19.050		348.988	234.293
36″	36.000	914	0.250	6.350		142.180	95.453
			0.281	7.137		159.672	107.196
			0.312	7.925	10	177.133	118.918
			0.375	9.525	STD	215.525	142.678
			0.438	11.125		247.790	166.353
			0.500	12.700	20 XHY	282.372	198.570
			0.625	15.875		351.723	236.128
			0.688	17.475		386.487	259.467
			0.750	19.050		420.576	282.353
42″	42.000	1067	0.312	7.925		206.914	138.911
			0.375	9.525	STD	248.319	166.708
			0.500	12.700	XHY	33.097	221.610
			0.750	19.050		492.163	330.413
48″	48.000	1219	0.375	9.525	STD	284.112	190.738
			0.438	11.125		331.404	222.487
			0.500	12.700	XHY	377.822	253.650
			0.750	19.050		563.750	378.473
			0.875	22.225		655.969	440.383

Imperial Dimensions of Inconel 625 Pipes Sizes

Pipe OD mm	Pipe WT mm	in.	Sch	Kg/m
13.72	1.65	1/4	10S	0.50
13.72	2.24	1/4	40S	0.64
13.72	3.02	1/4	80S	0.81
17.15	1.65	3/8	10S	0.64
17.15	2.31	3/8	40S	0.86
17.15	3.20	3/8	80S	1.12
21.34	2.11	1/2	10S	1.02
21.34	2.77	1/2	40S	1.29
21.34	3.73	1/2	80S	1.65
26.67	2.11	3/4	10S	1.30
26.67	2.87	3/4	40S	1.71
26.67	3.91	3/4	80S	2.23
33.40	2.77	1	10S	2.13
33.40	3.38	1	40S	2.54
33.40	4.55	1	80S	3.29
33.40	6.352)	1	160	4.30
42.16	2.77	1¼	10S	2.73
42.16	3.56	1¼	40S	3.44
42.16	4.85	1¼	80S	4.53
42.16	6.352)	1¼	160	5.69
48.26	2.77	1½	10S	3.16
48.26	3.68	1½	40S	4.11
48.26	5.08	1½	80S	5.49
60.33	2.77	2	10S	3.99
60.33	3.91	2	40S	5.52
60.33	5.54	2	80S	7.60
60.33	8.742)	2	160	11.29
73.03	3.05	2½	10S	5.35
73.03	5.16	2½	40S	8.77
73.03	7.01	2½	80S	11.59
88.90	3.05	3	10S	6.56
88.90	5.49	3	40S	11.47
88.90	7.62	3	80S	15.51
88.90	11.132)	3	160	21.67
101.60	3.05	3½	10S	7.53
101.60	5.74	3½	40S	13.78
101.60	8.08	3½	80S	18.92
114.30	3.05	4	10S	8.50
114.30	6.02	4	40S	16.32
114.30	8.56	4	80S	22.67
114.30	13.492)	4	160	34.05
141.30	6.55	5	40S	22.10
141.30	9.53	5	80S	31.44
141.30	15.882)	5	160	49.87
168.28	3.4	6	10S	14.04
168.28	7.11	6	40S	28.69
168.28	10.97	6	80S	43.21
168.28	14.27	6	120	54.75
168.28	18.262)	6	160	68.59
219.08	8.18	8	40S	43.20
219.08	12.7	8	80S	65.63
219.08	18.23	8	120	91.30
219.08	23.012)	8	160	112.97

Alloy Inconel 625 Pipes Pressure Rating

Pipe O.D. (In.)	Wall Thickness Of Pipe (Inches)
	.028	.035	.049	.065	.083	.095	.109	.120
	Working Pressure (Psig)
1/8	7900	10100
1/4	3700	4800	7000	9500
5/16		3700	5400	7300
3/8		3100	4400	6100
1/2		2300	3200	4400
3/4			2200	3000	4000	4600
1				2200	2900	3400	3900	4300

Welded Pipe Wall Thickness

Types	Out diameter	Wall thickness	Length
NB Sizes (in stock)	1/8” ~ 8”	SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160	Upto 6 Meters
Duplex 2205 Seamless Pipe (Custom Sizes)	5.0mm ~ 203.2mm	As per requirement	Upto 6 Meters
Duplex 2205 Welded Pipe (in Stock + Custom Sizes)	5.0mm ~ 1219.2mm	1.0 ~ 15.0 mm	Upto 6 Meters

Prices of Inconel 625 Pipes:

Stainless Seamless Pipe
6" to 10" Sch 10 , Sch 20
USD 6.23 Per Kg

Welded Pipe
6" to 10" Sch 40 , Sch 80
USD 6.18 Per Kg

Pipe
12" to 20" Sch 10 , Sch 20
USD 6.83 Per Kg

Hollow Pipe
12" to 20" Sch 40 , Sch 60/80
USD 6.50 Per Kg

Round Pipe
Sml 1" to 4" Sch 10
USD 6.91 Per Kg

Square Pipe
Sml 1" to 4" Sch 40
USD 8.49 Per Kg

stainless Rectangular Pipe
Sml 1" to 4" Sch 80
USD 7.25 Per Kg

Custom Pipe
Sml 1" to 4" Sch 160
USD 7.47 Per Kg

Cold Drawn Seamless Pipe
Sml 6" to 10" Sch 10
USD 10.92 Per Kg

Thick Wall Pipe
Sml 6" to 10" Sch 40
USD 12.66 Per Kg

Schedule 5S Pipe
SCH 5, 10, 40, 80, 160, XXH
USD 13.60 Per Kg

Schedule 40 Pipe
SCH10 (.188), SCH40 (.375)
USD 11.99 Per Kg

Stainless Polished Pipe
SCH-40 (.375)
USD 15.66 Per Kg

Electropolished Pipe
3 1/2" IPS( 4.000"O. D.)
USD 13.36 Per Kg

Exhaust Pipe
8 ” IPS(8.625"O. D.)
USD 14.60 Per Kg

Thin Wall stainless steel Pipe
18" IPS (18.000"O. D.)
USD 15.06 Per Kg

Applications :

These material are not a single material but the name for a family of corrosion resistant steels. Like many scientific breakthrough the origins of stainless steel lies in a lucky accident. From the smallest part of zipper to the largest building skyscraper, stainless steel is an essential part of modern life.Stainless steel’s strength, resistance to corrosion and low maintenance make it the ideal material for a wide range of applications. It is also has a long life cycle and is 100% recyclable.

Packaging Used By Us :

We ship our stainless steel metal products in industry leading packaging designed to ensure your order reaches its destination safely. We offer multiple packaging options to meet your specific requirements. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging. We pack our goods in numerous ways based on the products. We pack our products in multiple ways.

Testing Used By Us :

To specify the various physical and mechanical properties of the finished product, various tests, both destructive and nondestructive, are performed. Metallurgical, hardness, hardenability, tension, ductility, compression, fatigue, impact, wear, corrosion, creep, machinability, radiography, magnetic particle, ultrasonic, and eddy current are some of the major tests that are performed by quality control personnel. Metallurgical testing is used to determine the quality of steel by analyzing the microstructure of a sample under a microscope. A cross section of a sample is first highly polished and then examined at a magnification from 100-500 diameters. The microstructure of steel consists of grains of different compositions and sizes.
